PoE Bullet Camera

PoE Bullet Camera

An 3MP Internet protocol camera, or IP camera, is a type of digital video camera commonly employed for surveillance, and which, unlike analog closed-circuit television (CCTV) cameras, can send and receive data via a computer network and the Internet.


Image Sensor1/2.7” CMOS
Minimum Illumination                                                            0.02Lux/F1.85, 30IRE, 0Lux IR on
Effective Pixel2592(H) x 1944(V), 5MP
Shutter SpeedPal: 1/25~1/100000s NTSC: 1/30~1/100000s
White BalanceAuto / Manual
Gain Control (AGC)Auto / Manual
Lens3.6mm (2.8mm,6mm Optional)
Back Light CompensationBLC / HLC / WDR (100dB)
S/N RationMore than 65dB
Angle of ViewH: 77.5º (93º/49º)
Video Streaming20fps@5MP, 25/30@4MP, 25/30fps@1080P
Video Output1-channel BNC high definition video output / CVBS video output (Can switch)
Resolution5mp (2592×1944)(Can switch)
ICRAuto (ICR) / Manual
IRIR Range of 20Mtr
Operating Temperature-40ºC~+60ºC / Less than 95%RH
Power Source12V DC± 30%
Power ConsumptionMax. 3,6W (12V DC, IR on)
Weatherproof StandardIP67
Dimension97mm x 79.3m (3.8” x 3.1”)
